CodeBS0049

ONLINE CONDUCTIVITY CONTROLLER

Discription

Big LCD display
Auto Ranging (Automatic selection of range)
Auto zero

  • Simultaneously display of measured parameters
    Alarm output according to the upper and lower limits of conductivity
    Interface RS-232
    4-20mA Output.....

    • Request A Quote

    Big LCD display
    Auto Ranging (Automatic selection of range)
    Auto zero

  • Simultaneously display of measured parameters
    Alarm output according to the upper and lower limits of conductivity
    Interface RS-232
    4-20mA Output

    • Big LCD display
    • Auto Ranging (Automatic selection of range)
    • Auto zero
    • Simultaneously display of measured parameters
    • Alarm output according to the upper and lower limits of conductivity
    • Interface RS-232
    • 4-20mA Output
    LMICM-02
    Make
    Conductivity Range 0.00-20.00m;S/cm, auto ranging from 0-20.00μS/cm, 0-200.0μS/cm, 0-2000μS/cm, 0-20mS/cm
    Accuracy ±1% FS
    Temperature Compensation 0-60oC Automatic
    Display Conductivity, TDS, temperature, date and time simultaneously
    Electrode Cell constant selectable ( 0.1,1.0,10.0 )
    Alarm output Selectable according to the upper and lower limits of conductivity, output 220V / 6A
    Current Output Isolated 4 to 20mA output, various load, max. is 750W
    Interface RS-232 access to devices compatible with the interface such as computers, printers
    WorkingTemperature 0-50oC
    Humidity ≤85%
    Frame dimension(mm) 96 x 96
    Panel dimension (mm) 91 x91
    Depth (mm) 100
    Power Supply 220V / 50Hz
